Farm Implement

Disc Plough

The one-way disc plough is suitable for ploughing up the cultivated land as well as virgin land, especially on high yield’s manure land, wheat and rice stubble fields.
Product Details

Disc Plough

Disc Plough Disc Plough Disc Plough Disc Plough

The one-way disc plough is suitable for ploughing up the cultivated land as well as virgin land, especially on high yield’s manure land, wheat and rice stubble fields. Good pass ability and penetration, complete inversion and coverage. Moreover, the plough has the merits of less working resistance and easy to operate and adjust, etc.

Type 1LYQ-220 1LYQ-320 1LYQ-420 1LY-322 1LY-422 1LY-225 1LY-325 1LY-425 1LY-525 1LY-625
Working width (mm) 400 600 800 660 880 500 750 1000 1250 1500
Working depth (mm) 180-200 200-220 250-300
No. of disc (pc) 2 3 4 3 4 2 3 4 5 6
Dia. of disc (mm) 510 510 510 560 560 660 660/710 660/710 660/710 660/710
Weight (kg) 160 180 200 210 260 290 410 470 530 750
Linkage Three point mounted Three point mounted Type II three point mounted
Matched power (hp) 18-20 25-30 35-50 35-50 55-65 65-80 100-110 110-120
