Tractor

1804 Wheel Tractor 180HP Tractor

This series of tractors is a multi-purpose, high-horsepower agricultural wheeled tractor. This model has the characteristics of compact structure, convenient operation
Product Details

1804 Wheel Tractor 180HP Tractor

1804 Wheel Tractor 1804 Wheel Tractor 1804 Wheel Tractor 1804 Wheel Tractor 1804 Wheel Tractor 1804 Wheel Tractor

1804 Wheel Tractor Product Introduction
This series of tractors is a multi-purpose, high-horsepower agricultural wheeled tractor. This model has the characteristics of compact structure, convenient operation, flexible steering, large traction, wide range of uses, and convenient maintenance. It adopts TG large rear axle, four-wheel drive, 16F+16R gear transmission, full hydraulic power steering, dual clutches, comprehensive adjustment of force and position, and floating control suspension. It can be equipped with safety frame, hydraulic multi-way valve, heating and air-conditioning cab.

General Specification

Product Model                                                             1804
Wheel Drive                                                              4×4
Weight(Kg)                                                              7515
Front Wheet Tread(mm)                                                              1990
Rear Wheet Tread(mm)                                                 Adjustable(1740-1820)
Wheet Base(mm)                                                              2758
Minimum Land Clearance(mm)                                                               430
Gear Shifts                                                              16F+8R
Tire Size                                                    14.9-28/18.4-42
Dimension(L*W*H)(mm)                                                     5340*2398*3180

Engine specification

Brand                                                       Weichai/YTO
Type                                            4 Stroke, Water cooled, Vertical
Rated Power(KW)                                                        132.4
Rated Revolution(r/min)                                                         2200
Start Way                                                        Electrical starting
Clutch                                           Dry friction,Single Disc, Double Clutch
Power output(KW)                                                             116
